What is Cast Acrylic Sheet? Definition, Properties, and Applications

一文の定義

A cast acrylic sheet is a high-quality, transparent plastic panel made by pouring liquid polymethyl methacrylate (PMMA) into molds, then polymerizing and curing it to create a durable, optically clear, and customizable material.

詳細説明

Cast acrylic sheets are produced through a process where liquid PMMA is poured between glass plates or into molds, then chemically polymerized and cured. This method results in a material with exceptional optical clarity (up to 92% light transmission), high impact resistance (10–17 times that of glass), and excellent chemical and UV resistance. Cast acrylic is available in a wide range of thicknesses, colors, and finishes, making it suitable for both standard and highly customized applications. Compared to extruded acrylic sheets, cast acrylic offers superior surface hardness, better machinability, and more consistent molecular structure, though it is generally more expensive.

Key Components and Manufacturing Process

• Raw Material: PMMA monomer (polymethyl methacrylate)
• Casting: The monomer is mixed with initiators and poured into molds (often between glass plates)
• Polymerization: Heat or chemical catalysts trigger polymerization, turning the liquid into a solid sheet
• Curing: Sheets are post-cured (often in an autoclave) to remove internal stresses and enhance clarity
• Finishing: Edges are sanded and polished for a smooth, glossy finish; sheets can be cut, drilled, or laser-processed for custom shapes

For a visual overview, see Acme Plastics: How Are Acrylic Sheets Made?

実世界での応用

Cast acrylic sheets are widely used in:

• Retail and Commercial Displays: Premium display stands, branded storage boxes, and illuminated signage
• Architecture and Interior Design: Glazing, decorative panels, balustrades, and feature walls
• Security and Protection: Bullet-resistant barriers, protective shields
• Medical and Laboratory Equipment: Device housings, sterilizable components
• Aquariums and Water Features: Large, clear panels for tanks and viewing windows
• Home and Office Organization: Custom storage solutions, furniture, and trays

TOYIN Acrylic Products Co., Ltd. specializes in custom cast acrylic solutions for brands, retailers, and designers. Their products—ranging from display racks to protective covers—leverage the superior clarity, durability, and design flexibility of cast acrylic to meet high-end, multi-scenario needs. Learn more about TOYIN’s custom acrylic products.

関連概念

• Extruded Acrylic Sheet: Made by pushing melted acrylic through a die; more cost-effective but less optically pure and less customizable than cast acrylic. See comparison
• PMMA (Polymethyl Methacrylate): The base polymer for all acrylic sheets
• Acrylic Panel: A general term for flat acrylic products, including both cast and extruded types
• Polycarbonate Sheet: Another transparent plastic, known for even higher impact resistance but different optical and machining properties

References

• ISO 7823-1:2003, Plastics — Poly(methyl methacrylate) cast sheets
• Laird Plastics: What is Cast Acrylic?
• Acme Plastics: How Are Acrylic Sheets Made?
• Regal Plastics: Cast vs. Extruded Acrylic
